Triumph Tiger 900 Rally Pro (2020+)

Triumph Tiger 900 Rally Pro (2020+)




Category: Tag:

Specifications

Engine

888 cc Inline Triple, liquid-cooled

Power

93,9 hp @ 8750 rpm

Torque

87 Nm @ 7250 rpm

Transmission

6-speed, wet multi-plate slip/assist clutch, quick-shifter, chain final drive

Fuel Capacity

20 liters

Length

2254 mm (estimated)

Width

935 mm

Height

1452 mm / 1502 mm (low/high screen position)

Weight

201 kg dry

Seat Height

850-870 mm (adjustable)

Suspension

– Front: Showa 45 mm inverted fork, manual preload, rebound damping and compression damping adjustment, 240 mm travel
– Rear: Showa mono-shock, manual preload and rebound damping adjustment, 230 mm wheel travel

Tyres

– Front: 90/90-21
– Rear: 150/70-17
– Tubeless

Brakes

– Front: 320 mm floating discs, Brembo Stylema 4-piston monobloc calipers
– Rear: 255 mm disc, Brembo 1-piston sliding caliper
– cornering ABS available

Instruments

7 inch TFT display with speedometer, tachometer, gear indicator, fuel gauge, dual trip meters, clock

Other

LED lights, Riding modes, cornering traction control, under seat phone storage and USB charging, smartphone connectivity, illuminated switches, cruise control, heated grips, heated seat with separate pillion control, TPMS, LED fog lights, centre stand
