Goldwing GL1800

Brand: Style:
Share:

Specifications

Engine

1833 cc horizontally opposed 6-cylinder, liquid-cooled

Power

125 hp @ 5500 rpm

Power to weight

33 HP/Kg x 100

Torque

169 Nm @ 4500 rpm

Torque to weight

44 Nm/Kg x 100

Transmission

– 6-speed manual + reverse, wet multi-plate slip/assist clutch, or 7-speed DCT + reverse
– Shaft final drive
– Optional: DCT Foot Shifter

Fuel Capacity

21 liters

Length

2615 mm

Width

925 mm MT, 905 mm DCT

Height

1430 mm

Weight

385 kg wet (390 kg DCT with Air Bag)

Seat Height

745 mm

Suspension

– Front: double wishbone, mono-shock, electronically adjustable damping, 110 mm travel
– Rear: Showa mono-shock, electronically adjustable damping, adjustable preload, 105 mm travel

Tyres

– Front: 130/70-18
– Rear: 200/55-16

Brakes

– Front: 320 mm floating discs, Nissin 6-piston radial calipers
– Rear: 316 mm disc, Nissin 3-piston caliper
– ABS available, linked brakes

Instruments

– Analogue speedometer and tachometer, 7" TFT touchscreen, LCD displays with odometer, fuel gauge, gear indicator, trip meters, range, engine temperature
– smartphone connectivity, navigation

Other

– LED lights, self-cancelling indicators, LED fog lights (2020+)
– Riding modes, traction control, braking force distribution
– Cruise control, 2x USB-C ports, fully keyless (incl. luggage), hill-hold, TPMS, electric screen adjustable for angle and height, sound system, idling stop (DCT). Optional: Air bag, centre stand
– Storage: saddlebags 30 litres each, top box 50 litres (61 litres 2020+), smartphone compartment
