Honda CB500 Hornet / CB500F (2024+)

US: CB500F


Brand: Style:
Share:

Specifications and Features

Engine

471 cc Parallel-twin, liquid-cooled

Power

47 hp @ 8600 rpm

Power to weight ratio

25 HP/100kg

Torque

43 Nm @ 6500 rpm

Torque to weight ratio

23 Nm/100kg

Transmission

– 6-speed, wet multi-plate slip/assist clutch
– Chain final drive

Fuel Capacity

17,1 liters

Length

2080 mm

Width

800 mm

Height

1060 mm

Weight

– 188 kg wet
– Max load: 168 kg

Seat Height

785 mm

Suspension

– Front: Showa 41 mm separate function USD fork, 110 mm travel
– Rear: mono-shock, adjustable preload, 120 mm travel

Tyres

– Front: 120/70-17
– Rear: 160/60-17

Brakes

– Front: 296 mm discs, Nissin 2-piston radial calipers
– Rear: 240 mm disc, 1-piston caliper
– ABS available

Instruments

– 5" TFT display with speedometer, tachometer, gear indicator, fuel gauge, dual trip meters, shift-up indicator, coolant temperature, clock
– smartphone connectivity

Other

– LED lights, emergency braking blinking lights
– Traction control
– Optional: 12v socket

Honda CB500 Hornet 2024 dashboard Honda CB500 Hornet 2024 front Honda CB500F 2024 Matte Black Metallic back
